The Head Size determines the complexity of each term in your model. In the heads of genes, the APS learning algorithm tries out different arrangements of functions and terminals (variables and constants) in order to model your data. The plasticity of this architecture allows the discovery of a virtually infinite number of models of different sizes and shapes which are afterwards tested and selected during the learning process.

More specifically, the head size h of each gene determines the maximum width w and maximum depth d of the sub-expression trees encoded in the gene, which are given by the formulas:

w = (n - 1) * h + 1

d = (h + 1) / m * (m + 1)/2

where m is minimum arity and n is maximum arity.

Thus, the APS learning algorithm selects its models between these extreme cases, fine-tuning the ideal size and shape during the evolutionary process without human intervention.

The number of genes per chromosome is also an important parameter. It will determine the number of (complex) terms in your model as each gene codes for a different parse tree (sub-expression tree or sub-ET). Theoretically, one could just use a huge single gene in order to evolve very complex models. But the partition of the chromosome into simpler, more manageable units gives an edge to the learning process and more efficient and elegant models can be discovered using multigenic chromosomes.

Whenever the number of genes is greater than one, you must also choose a suitable linking function to link the mathematical terms encoded in each gene. APS 3.0 allows you to choose addition, subtraction, multiplication, or division to link the sub-ETs. As expected, addition (and obviously subtraction) works very well for virtually all problems but sometimes one of the other linkers could be useful for searching different solution spaces and finding a very good, albeit unexpected model.
